The 2812 1000KV motor is a traction solution for platforms that require maximum stability at low speeds and high efficiency with large propellers. Thanks to its larger stator (12 mm high), the motor delivers powerful traction and control even under heavy load.
The low KV combined with the 12N14P configuration ensures smooth dynamics and reduced vibrations. This makes it possible to use the motor in projects where control accuracy, energy efficiency, and long service life are critical.
Ideal for 5S-6S platforms with 11-13 inch diameter propellers.
Advantages.
Maximum traction at low speeds. Thanks to the large stator volume (2812), the motor develops stable torque even at high speeds – ideal for applications with heavy loads or large screws.
Optimization for large propellers. The KV configuration allows you to work with 11-13” propellers without overloading, while maintaining efficiency and control.
Smooth response, minimal vibrations. High-precision rotor balancing, a rigid shaft and bearings reduce mechanical vibrations – this contributes to stable operation even at peak currents.
Improved cooling. Ventilation channels in the rotor and an open housing ensure efficient heat dissipation during intensive operation.
Readiness for long-term missions. The motor is capable of operating in 5S-6S configurations with sustained loads without overheating, making it versatile for demanding applications.
Model: 2812
KV: 1000 rpm/V
Configuration: 12N14P
Operating voltage: 5S-6S LiPo (up to 25.2V)
Maximum current: up to 60 A
Peak power: up to 1300-1400 W
Compatible with propellers: 11″-13″
Shaft: 4 mm, hardened steel
Propeller mount: M5 thread with locking device
Mounting base: 16 × 16 mm (4 × M3)
Wires: 18 AWG, 150 mm, silicone insulation
Weight: ~60-62 g (without cables)
Bearings: NSK / analog (low friction)
Cooling: open rotor with radial channels
2812 – 1000KV
Original price was: 4 000₴.3 600₴Current price is: 3 600₴.
In stock
The 2812 1000KV motor is a traction solution for platforms that require maximum stability at low speeds and high efficiency with large propellers. Thanks to its larger stator (12 mm high), the motor delivers powerful traction and control even under heavy load.
The low KV combined with the 12N14P configuration ensures smooth dynamics and reduced vibrations. This makes it possible to use the motor in projects where control accuracy, energy efficiency, and long service life are critical.
Ideal for 5S-6S platforms with 11-13 inch diameter propellers.
Advantages.
Maximum traction at low speeds. Thanks to the large stator volume (2812), the motor develops stable torque even at high speeds – ideal for applications with heavy loads or large screws.
Optimization for large propellers. The KV configuration allows you to work with 11-13” propellers without overloading, while maintaining efficiency and control.
Smooth response, minimal vibrations. High-precision rotor balancing, a rigid shaft and bearings reduce mechanical vibrations – this contributes to stable operation even at peak currents.
Improved cooling. Ventilation channels in the rotor and an open housing ensure efficient heat dissipation during intensive operation.
Readiness for long-term missions. The motor is capable of operating in 5S-6S configurations with sustained loads without overheating, making it versatile for demanding applications.
Model: 2812
KV: 1000 rpm/V
Configuration: 12N14P
Operating voltage: 5S-6S LiPo (up to 25.2V)
Maximum current: up to 60 A
Peak power: up to 1300-1400 W
Compatible with propellers: 11″-13″
Shaft: 4 mm, hardened steel
Propeller mount: M5 thread with locking device
Mounting base: 16 × 16 mm (4 × M3)
Wires: 18 AWG, 150 mm, silicone insulation
Weight: ~60-62 g (without cables)
Bearings: NSK / analog (low friction)
Cooling: open rotor with radial channels
